Tight die cast alluminum body has excellent heat dissipation, effectively prolongs lamp lifespan.
External waterproof LED driver with over-temp, over-current, overload protection function.
Tempered glass, rubber+silicone seal, internal epoxy potting, good waterproof performance.
Metal bracket allows flexibly installation including ceiling-mounted, wall-mounted and ground.
Standard module, pluggable technology, Convenient storage,Simple installation and maintenance;
Professional heat dissipation structure, transparent inside and outside duct design,efficient radiating performance;
The shell of the paint processing, radiator anodized,has good corrosion resistance, suitable for harsh
outdoor environment;
Products are waterproof joints and silicone pad sealing process, the protection level of IP65, suitable for a
variety of harsh outdoor environment;
180 degree adjustable bracket, easy installation, suitable for different installation sites.
Product Parameters
| Rated Power | 120w | 160w | 200w | 240w | 320w | 400w | 480w |
| Power supply | AC85～260V | ||||||
| Luminous Flux | 14400lm | 19200lm | 24000lm | 28800lm | 38400lm | 48000lm | 57600lm |
| LED Junction Temperature | <100℃ | ||||||
| LED Efficiency | ＞120 Im/W | ||||||
| Color Temperature | 3000K/4000K/5000K/6000K | ||||||
| Operating temperature | -35℃～50℃ | ||||||
| Working Humidity | 10%-90% | ||||||
| IP Rating | IP66 | ||||||
| IK Rating | IK08 | ||||||
| Lamp Life | >70000H | ||||||
| Lamp Dimension | 600×380×82mm | ||||||
| Remark | Color Temperature,Wattage and optical angle can be customized. All parameters are tested at 25℃ ambient temperature,65% humidity laboratory environment. All luminous flux is the maximum value among all kinds of light distribution. |
||||||
| Warranty | 3 Years | ||||||
Product Parameters
| Rated Power | 60w | 120w | 180w | 240w | 300w |
| Power supply | AC85～260V | ||||
| Luminous Flux | 7200lm | 14400lm | 21600lm | 28800lm | 36000lm |
| LED Junction Temperature | <100℃ | ||||
| LED Efficiency | ＞120 Im/W | ||||
| Color Temperature | 3000K/4000K/5000K/6000K | ||||
| Operating temperature | -35℃～50℃ | ||||
| Working Humidity | 10%-90% | ||||
| IP Rating | IP66 | ||||
| IK Rating | IK08 | ||||
| Lamp Life | >70000H | ||||
| Lamp Dimension | 400×360×150mm | ||||
| Remark | Color Temperature,Wattage and optical angle can be customized. All parameters are tested at 25℃ ambient temperature,65% humidity laboratory environment. All luminous flux is the maximum value among all kinds of light distribution. |
||||
| Warranty | 3 Years | ||||
Product Benefits
High-purity aluminum reflector, the most precise light beam and the best reflection effect.
Symmetrical narrow-angle, wide-angle and asymmetric light distribution systems.
The back opening style allows replacement of bulbs, making maintenance easy.
Integrate the resources of strategic partners to create industr
①The lighting area is large and the lighting brightness effect is good.Concentrated light source,uniform lllumination and samll glare. éasy to control and maintain.
②Applicationa: city squares,stations, docks, highways, stadiums, overpasses,etC
③The light pole is treated by hot-dip galvanizing and anti-corrosion. it is anigh-qualty steel plate molded polygonal pyrarid plug-in steel pole.
④The frame of the lamp bracket is made of stainless steel.
light source: sodium lamp, LED
⑤The foundation is made by drawing provided by our factory separately, and the lamp body must be safety grounded during installation.
